BMC Teammachine SLR FOUR

Frameset

Frame:
Teammachine SLR Carbon with Aerocore Design | ICS Technology Stealth Cable Routing | Stealth Dropout Design | TCC Race compliance level | Flat Mount Disc | 12 x 142mm Thru-Axle | Optimized for Aerocore Bottle Cages

Fork:
Teammachine SLR Carbon | ICS Technology Stealth Cable Routing | TCC Race Compliance Level | Stealth Dropout Design | Flat Mount Disc | 12 x 100mm Thru-Axle | 48mm offset Size 47-51 | 43mm offset Size 54-61

Cockpit

Stem:
BMC RSM 01 | Integrated Cockpit System Technology

Handlebar:
BMC RAB 02 | Ergo Top Shape | Compact Bend [or] BMC HB D4 03, 0, 6 | Alloy 6061 | 135mm drop, 70mm reach, 6° flare

Seat

Seatpost:
Teammachine SLR Carbon D-Shaped Seatpost | 15mm Offset

Saddle:
Fizik Antares R7 | S-Alloy rail 140mm [or] Selle Italia Model X Superflow | FeC Alloy rail | 145mm

Drivetrain

Crankset:
SHIMANO 105 (FC-R7100)

Chainrings:
50-34T

Cassette:
SHIMANO 105 (CS-R7101)

Cassette Size:
11-34T

Chain:
SHIMANO CN-M6100

Front Derailleur:
SHIMANO 105 (FD-R7100)

Rear Derailleur:
SHIMANO 105 (RD-R7100)

Shifters:
SHIMANO 105 (ST-R7120)

Gears:
2 x 12

Bottom Bracket:
SHIMANO Press-Fit Bottom Bracket (BB-RS500-PB)

Brakes

Brake Levers / Calipers:
SHIMANO 105 (BR-R7170)

Rotors:
SHIMANO SM-RT70 | Centerlock

Rotor Size (F/R):
160 / 160mm

Wheels

Rims:
PRD23 | 23mm

Hubs (F/R):
SHIMANO HB-TC500-12 & FH-TC500-HL | Center Lock| 28H

Tires:
Pirelli P7 Sport | 26mm

Tubeless Information:
Non-Tubeless Rims | Non-Tubeless Clincher Tire

Additional Information

Tire Clearance:
30mm measured tire

Weight without Pedals:
8.5kg | Size 54 as pictured with all accessories

ASTM Classification:
Level 1

System Weight Limit:
110kg
